    Customized capacitive touch screen IPS TFT LCD screen 10.25-inch FHD LVDS display module

    Ask Lasest Price
    Brand Name : TXWEI
    Model Number : TXW103002S0
    Certification : ISO9001 IS014001 IATF16949
    Price : negotiations
    Payment Terms : L/C, T/T
    Supply Ability : 100000pcs
    Delivery Time : 5-8day
    • Product Details
    • Company Profile

    Customized capacitive touch screen IPS TFT LCD screen 10.25-inch FHD LVDS display module


    IPS TFT LCD Screen 10.25 Inch FHD LVDS Display Product Introduction


    A 10.25-inch FHD LVDS display module typically refers to a liquid crystal display with a 1920 * 720 full HD resolution, featuring a 10.25-inch IPS TFT LCD panel and an enhanced display interface (LVDS). Here are some key product features and parameters of TXW103002S0:


    Panel type: IPS TFT LCD, providing wide viewing angle and color accuracy.
    Resolution: 1920 × 720 pixels, also known as Full HD (FHD) resolution, providing clear image details.
    Brightness: The brightness of different models may vary, but it is generally around 1000cd/m², suitable for various usage environments.
    Contrast ratio: 800:1, providing excellent light and dark detail representation.
    Perspective: IPS technology provides a nearly 180 ° perspective, allowing color and contrast to be maintained from different angles.
    Response time: usually around 30ms, sufficient for non professional graphic applications.
    Color gamut: Covering 72% of the NTSC color gamut, capable of displaying rich colors.
    Interface: LVDS interface, supporting 0 pin terminal connection, providing high-speed data transmission.
    Backlight type: WLED backlight, providing uniform brightness and longer lifespan.
    Working temperature: generally between -30 and 85 ° C, suitable for various environmental conditions.
    Capacitive touch screen: Customized capacitive touch screen function, supporting multi touch. Allow users to interact through touch. Capacitive touch screens have the characteristics of high transparency and fast response, making them suitable for applications that require direct interaction.
    This product is widely used in car dashboards, car navigation, 3D printers, and other products

    General Information ItemsSpecificationUnit
    Display area(AA)

    243.648*91.368

    mm

    Mechanical OutlineSize(W*H*T)

    258.8*111.1*7.55

    mm
    Driver elementa-Si TFT active matrix-
    Display colors16.7Mcolors
    Number of pixels

    1920*720

    dots
    Pixel arrangementRGB vertical stripe-
    Pixel pitch

    0.13269*0.13269

    mm
    Viewing angleALLo'clock

    Lcm pin n count

    50pin

    pin
    Color Pixel ArrangementRGB vertical stripe-
    Display modeTransmissive/ Normally Black-
    Operating temperature

    -30+85

    Storage temperature

    -40+90


    Product Drawing



    Interface Pin Definition



    Back-Light Unit Characeristics

    The back-light system is an edge-lighting type with 36 white LEDs. The characteristics of the back-lightare shown in the following tables.

    CharacteristicsSymbolMin.TypeMax.UnitNotes
    Forward VoltageVF27.9--29.7V--
    Forward currentIF--300--mA--
    Luminance(With LCD)Lv7501000--cd/m2--
    LED life timeN/A--20,000--HrNote 1

    Reliability Test Item


    No.Test ItemTest ConditionNotes
    1High Temp. Storage+90°C / 96H

    1. Functional test isOK.

    Missing Segment,short, unclear segment non-display,display abnormally and liquid crystal leakare un-allowed.

    2. No low

    temperature bubbles,end seal loose andfall, frame rainbow.


    2Low Temp. Storage-40°C / 96H
    3High Tempe. Operating+85°C / 96H
    4Low Tempe. Operating-40°C / 96H
    5High Temperature /Humidity storage60°C x 90%RH /96H
    6Thermal and cold shockStatic state, -40℃(30min) ~85℃ (30min),10 cycles

    Product Image


    This article mainly analyzes the core elements of LCD display screen selection, and provides differentiated selection strategies by analyzing key parameters such as resolution, brightness, and contrast, combined with the needs of industrial control, smart home, and car applications. Simultaneously revealing market price patterns and future technological trends, helping consumers accurately match products with demand
